Warranty: | 1 Year | Overall Dimensions: | 1700mm X 800mm X 1300mm |
---|---|---|---|
Lifting Speed: | 0.05m/s | Max. Lifting Height: | 200mm |
Lifting Motor: | 24V/2.2kW | Battery Capacity: | 24V/210Ah |
Min. Turning Radius: | 1350mm | Load Capacity: | 1500kg |
Charging Time: | 8 Hours | Battery Type: | Lead-acid |
Driving Speed: | 4.5km/h | Driving Motor: | 24V/1.5kW |
Net Weight: | 350kg | ||
Highlight: | 4000W Electric Pallet Trolley,Pedestrian Electric Pallet Trolley,4000W electric walkie pallet jack |
2T Electric Steering Pallet Truck (Lithium-Ion Battery Version)
The 2T Electric Steering Pallet Truck (Lithium-Ion Battery Version) is an electric handling equipment that uses lithium-ion batteries as the power source and is equipped with an electronic steering system. The relevant introduction is as follows:
Performance Parameters
- Sany Heavy Industry SCB20W: Rated load of 2t, battery voltage of 48V, optional battery capacity of 15Ah/20Ah/25Ah, maximum travel speed of 4.5km/h (no-load) and 4.3km/h (loaded), maximum lifting speed of 22mm/s (no-load) and 17mm/s (loaded).
- Sinolift EPT20E: Rated load of 2000kg, 48V 15Ah lithium-ion battery, normal working time of approximately 3.5 hours, and full charging time of about 4 hours. Parameters such as maximum travel speed are not clearly specified.
Features
- Powerful and Environmentally Friendly: Powered by lithium-ion batteries. For example, the Luhuan LH-2T electric forklift is equipped with a 4000W AC motor for hydraulic lifting, providing strong and stable power. Meanwhile, lithium-ion batteries are pollution-free, meeting environmental protection requirements.
- Flexible Steering: Some models, such as the Luhuan LH-2T, adopt hydraulic power steering with a small turning radius, enabling 90° in-place steering for flexible operation in narrow spaces.
- Convenient and Comfortable Operation: Some models are equipped with ergonomic handles. For instance, Linde's 2T electric steering pallet truck features easy-to-operate handles that reduce operator fatigue, and some handles are equipped with password locks to enhance security.
- Good Endurance: Some lithium-ion battery-powered pallet trucks have excellent endurance. For example, a certain
