Walkie Pallet Truck: 1.5T Electric Pallet Truck F5/F5PRO (Lithium-Ion Green) Product Introduction
General Overview
The F5 and F5PRO (Lithium-Ion Green) are 1.5-ton electric walkie pallet trucks built around high-performance lithium-ion power systems, tailored for eco-friendly, efficient light-to-medium-duty handling. Designed for small warehouses, retail backends, electronics workshops, and fresh logistics centers, the F5 focuses on cost-effectiveness for daily basic operations, while the F5PRO adds upgraded performance for high-frequency tasks—both featuring the iconic "Lithium-Ion Green" design to emphasize low-carbon operation.
Performance Parameters (F5 vs. F5PRO)
Parameter F5 (Standard) F5PRO (Upgraded)
Load Capacity Rated load: 1500kg; Load center: 600mm; Static load: 3000kg Rated load: 1500kg; Load center: 600mm; Static load: 3500kg
Power System 24V/50Ah LiFePO₄ battery; 0.6kW drive motor + 0.7kW lifting motor; 6–7h continuous operation 24V/60Ah LiFePO₄ battery; 0.7kW high-torque drive motor + 0.8kW lifting motor; 8–9h continuous operation
Charging Speed 80% charge in 1.5–2h (220V charger) 80% charge in 1–1.5h (220V fast charger)
Travel Speed 3.5km/h (loaded) / 4.0km/h (unloaded) 4.0km/h (loaded) / 4.5km/h (unloaded)
Lifting/Lowering Speed Lifting: 18mm/s (loaded)/25mm/s (unloaded); Lowering: 35mm/s (loaded)/28mm/s (unloaded) Lifting: 20mm/s (loaded)/28mm/s (unloaded); Lowering: 36mm/s (loaded)/30mm/s (unloaded)
Climbing Ability Max slope: 5% (loaded) / 12% (unloaded) Max slope: 6% (loaded) / 15% (unloaded)
Dimensions & Structure
• Shared Dimensions:
◦ Overall length: 1550mm; Overall width: 550mm (680mm optional for wide pallets); Minimum turning radius: 1420mm (fits 1.7m-wide aisles).
◦ Fork size: 45mm×140mm×1150mm (1220mm optional); Outer fork width: 530mm (670mm optional); Fork height: 80mm (lowered) / 110mm (raised).
• Structural Strength:
◦ Both models use Q345 manganese steel forks (45mm thick) with reinforced root welds and 3mm-thick reinforced steel chassis.
◦ F5PRO adds a drive axle reinforcement bracket and uses wear-resistant polyurethane drive wheels (Φ220mm, vs. Φ200mm for F5) for longer service life.
• Battery Safety:
◦ Flame-retardant V0-grade battery compartments (IP65 dustproof/waterproof); LiFePO₄ batteries with overcharge/over-discharge/short-circuit protection.
Product Features
1. Core "Lithium-Ion Green" Advantages (Both Models)
• Eco & Lightweight: Zero heavy metal pollution; lithium batteries are 50% lighter than lead-acid batteries of the same capacity (F5 net weight: ~260kg; F5PRO: ~280kg), reducing maneuvering effort.
• Long Lifespan: Battery cycle life ≥2000 times (3–5 years of use), 2–3x longer than lead-acid batteries; no memory effect, supporting flexible partial charging.
2. Model-Specific Upgrades (F5PRO)
• High-Frequency Adaptability: Upgraded motor and larger battery handle 80–100 daily pallet moves (vs. 50–70 for F5), ideal for busy logistics hubs or retail backends.
• Fast-Charging Convenience: 1–1.5h fast charging cuts downtime—suitable for multi-shift operations where quick power replenishment is needed.
• Intelligent Monitoring: 2.4-inch LCD display (vs. 2.0-inch for F5) shows real-time battery level, working hours, and fault codes (e.g., motor overload) for faster troubleshooting.
3. Shared User-Friendly & Safety Features
• Ergonomic Operation: Curved anti-slip tiller grip (10° angle) fits palms; one-key lifting/lowering and 2-speed adjustment (low for precision, high for efficiency) enable one-hand control.
• Reliable Safety: Electromagnetic brake (auto-brakes in 0.5s when tiller is released); red emergency power-off switch; non-slip pedal (160mm wide) to prevent foot slippage.
• Low Maintenance: Fully maintenance-free lithium batteries (no water/electrolyte checks); modular electrical components (centralized wiring) simplify inspection and replacement.
Applications
Model Ideal Scenarios Typical Use Cases
F5 Basic daily handling (low-to-medium frequency) Small warehouses (unloading small-batch goods); retail backends (moving goods to sales floors); small workshops (light part transfer).
F5PRO High-frequency, long-shift operations Fresh logistics (cold storage-to-sales transport); e-commerce fulfillment centers (high-volume small-pallet sorting); electronics workshops (low-noise component transfer).
